AUTO VIA (1)

- Automatic Via Instanciation

- TOOLBOX can create Vias by cols & rows between any two layers

ADD PATH (2)

Add path quikly

CLONE PATH (3)

Duplicate a path very easily.

JOINT (4)

Interactive path creator

AUTO CONNECT (5)

Connect a group of wires with another group of wires.

STEP ROUTER(6)

Step Router: create an auto-connection along the user-input routing coordinates

Introduces a click-and-connect routing method for custom layout design

It automatically adds vias and jumps routing layers

The connection also meets constraints such as minimum array size (columns/rows) of vias

MESH (7)

Create mesh structure.

SHIELD (8)

Create shielding

SLOT (9)

Il s'agit d'une macro qui ...

JUMPER (10)

Jumper which enables the user to jump routing layers between any two metals

The Jumper automatically places wire and a proper via on metal jumping.

So the user can change routing metals by one click

PLACE PIN(11)

Sort pins aphabetically

Select size, position, layers ...

AREA(12)

Calculating shapes area (polygon).

ISOLATION(13)

Generate ROD isoring around selected mos

ALIGN(14)

Align mos

POLY CONTACT(15)

Place gate contact

VIA ARRAY(16)

Generate via array to verify bulge DRC rule (density)

ZOOM(17)

Enter XY coordinate and zooming into the layout

MPP ADVANCED (18)

Insert new multpart path

POWERMOS (19)

Advanced script to generate powermos device with metalization.
